RLV 515TR/W 4-speed
The RLV 515TR/W is a lawn mower available exclusively at texas.dk, where you get a powerful self-propelled lawn mower with multiple gears, a unique sleek design, and plenty of mowing options combined with smart functions - making it easy to handle lawns up to 600 m².
Description
The TEXAS RL series of lawn mowers is designed with extra focus on features and design - and you will only find the RLV 515TR/W 4-Speed and the other RL models at texas.dk. The series stands out with its stylish, minimalist look, featuring a matte black steel cutting deck.
But the RLV 515TR/W 4-Speed is more than just attractive. It is powered by an extra-strong TEXAS TG670 engine with 196 cc, delivering plenty of cutting power. The steel cutting deck is extremely durable and resistant to stone impacts.
Weighing just 38.5 kg and equipped with extra-large rear wheels, the mower is stable and easy to maneuver. With rear-wheel drive, it moves effortlessly across the lawn.
The special feature of the RLV 515TR/W 4-Speed is its 4-speed function, allowing you to choose between four different driving speeds - without compromising blade revolutions. This way, you can set your own pace while still mowing with maximum cutting performance.
How it mows
The RLV 515TR/W 4-Speed comes with a 4-in-1 function, giving you full flexibility when mowing. With rear discharge or side discharge, the mower expels grass behind or to the right side. With mulching, the grass is finely chopped and spread across the lawn as natural fertilizer. With the collector box, you get a clean and neat finish without grass residue.
The included large 65 L collector box efficiently gathers clippings, allowing you to mow for a long time before emptying. It also has a smart indicator that shows when the box is full.
Central height adjustment makes it easy to set the cutting height using the large lever by the rear wheel. Choose between 6 positions from 28- -75 mm, whether you want a precise short cut or prefer a longer lawn.
With a cutting width of 51 cm, the RLV 515TR/W 4-Speed covers a wide area with each pass, making it capable of handling lawns up to 600 m².
Product details
The RLV 515TR/W 4-Speed starts with a recoil starter while you hold the safety handle - activate the second lever, and the self-propulsion engages to help with forward drive. The ergonomic handlebar is height-adjustable for optimal comfort, and the soft grip ensures a pleasant mowing experience.
On the handlebar, you will also find the speed selector, where you choose the driving speed of the mower, while the choke lever on the opposite side assists when starting. As an extra touch, a cup holder is included so you can enjoy a refreshment while mowing.
The RLV 515TR/W 4-Speed also comes with a practical front lifting handle, making it easier to move.
Cleaning is simple with the built-in water nozzle: just connect your garden hose and start the engine, and the blade will wash the cutting deck clean of most grass residues.
With the RLV 515TR/W 4-Speed you get a powerful petrol lawn mower with a unique and stylish appearance, combined with user-friendly functions such as 4-speed and multiple mowing options - making mowing easier and more enjoyable. If you appreciate extra attention to detail in your equipment, this lawn mower is the right choice for you.
Please note
The machine is supplied without oil.
TEXAS recommends using unleaded 98/100 gasoline (also called E5) for all our gasoline engines, even if the manual specifies unleaded 95 gasoline (E10).
This recommendation is due to changes from January 1, 2020, when unleaded 95 gasoline (E10) began to contain 10% bioethanol instead of the previous 5%. The increased bioethanol content attracts condensation/water over time and shortens the fuel's shelf life, which can lead to poorer combustion and starting issues.
TEXAS recommends
Remove moss from your lawn
Frequent mowing promotes healthy lawn growth, but if your lawn is filled with moss, you may need stronger solutions. Explore our wide selection of lawn aerators and dethatchers, giving your lawn mower a reliable companion to help you achieve a beautifully maintained lawn.
Grass trimmer for edges
Reaching every corner can be challenging, even with the best lawn mower. A simple grass trimmer is the perfect partner for quickly and easily trimming lawn edges.
Specifications
Engine
Engine
: Texas
Engine model
: TG670
CC
: 196 cc
Engine type
: 4 stroke
Tank capacity
: 1 litre
Power
: 3,6 kW v. 2800 rev./min.
Noise level
: 98 dB
Airfilter
: Paper with foam filter
Cylinder
: 1
Starter
: Recoil
Functions / Equipment
Collecting box
: 65 litre
Cutting height
: 28-75 mm
Cutting width
: 51 cm
Dispatch tupe
: Yes
Engine oil
: 0,6 litre
Forward gears
: 4
Gasoline/diesel
: Gasoline
Handle bar
: Adjustable
Height ajustment
: Central
Knife
: Metal
Mulching
: Yes
Number of high adjustments
: 6 positions
Number of knives
: 1 pce.
Oil
: SAE 30
Pull
: Yes
Rear discharge
: Yes
Rear wheel drive
: Yes
Shield material
: Steel
Speed forward max
: 2,3-4,3 km/hr
Dimensions
Box length
: 57 cm
Box width
: 83 cm
Box height
: 49 cm
Weight
: 38,5 kg
Info
Manufacturer
Texas A/S
| Knullen 22 | DK-5260 Odense S | Denmark
Tel. +45 6395 5555 | www.texas.dk | VAT DK 66212319
