XC140-98

Product data
Art no : 90063129
EAN : 5708906932016
Catalogues
EN
(2021)
DE
(2021)
ES
(2021)
More catalouges avaible in local language

Where to buy

Documentation

Manual Reservedele

Productdescription XC140-98


TEXAS XC models are built on a strong frame and fitted with powerful engine.

TEXAS XC140-98 is a lawn tractor with a powerful 432 cc Loncin engine. and 18 V electric start function.

XC140-98 is with a 6-speed transmission (5 gears forward and 1 reverse). The gear options ensure the right working speed, whether the machine is used for cutting grass or for pulling a trolley or other accessories.

XC140-98 has a cutting width of 98 cm and there is a 7-step height adjustment from 30-90 mm, and a turning radius of only 45 cm.

The model has several small practical features:
1. A front bumper protects the lawn tractor from damage.
2. All control levers are conveniently located near the driver's seat
3. Extra large fuel tank of about 7.5 liters.

Mulching kit is included, so that you have possibility for mulching or side discharge. The model has a trailer hook for rearmounted accessories such as trailer, scarifier or grass / leaf collector).




Specifikationer


Engine
Engine : Loncin
Engine type : 4 stroke
CC : 432 cc
Tank capacity : 7,5 litre
Output (Max) : 8,8 kW v. 3600 rev./min.
Power : 8,0 kW v. 2800 rev./min.
Starter : Electric
Tank
Oil : SAE 30
Gasoline/diesel : Gasoline
Engine oil : 1,2 litre
Equipment
Mulching : Yes
Dispatch tupe : Yes
Functions
Cutting height : 30-90 mm
Cutting width : 98 cm
Trailer hook : Yes
Number of knives : 2 pce.
Height ajustment : Central
Knife : Metal
Kniv clutch : Manual
Shield material : Steel
Number of high adjustments : 7 positions
Front light : Yes
Adjustable seat : Adjustable
Speed : 1,6-8,3 km/hr
Operation
Rear wheel drive : Yes
Rearward gears : 1
Forward gears : 5
Gear system : Manual
Wheels
Wheel size front : 15 x 6.00-6
Big air pressured rubber wheels : Inflatable rubber tyres
Wheel size rear : 18 x 8.50-8
Battery
Power : 12V/18 Ah
Emission
LWA guaranteed : 100
Dimensions
Machine width : 121 cm
Machine length : 173 cm
Machine height : 105 cm
Weight : 165 kg
Box width : 171 cm
Box length : 110 cm
Box height : 84 cm
